Processor parameter for referance only
|
Processors |
Cores & Threads |
L3 Cache |
Base Frequency |
Max Turbo Frequency |
TDP |
Graphics |
|
Ryzen 9 7940HS |
8 cores, 16 threads |
16M |
4.0GHz |
5.2GHz |
35-54W |
AMD Radeon 780M 12 Core 2800MHz |
|
Ryzen 7 7840HS |
8 cores, 16 threads |
16M |
3.8GHz |
5.1GHz |
35-54W |
AMD Radeon 780M 12 Core 2700MHz |
|
Ryzen 9 6900HX |
8 cores, 16 threads |
16M |
3.30 GHz |
4.90 GHz |
45W |
AMD Radeon 680M 12 Core 2400MHz |
|
Ryzen 7 6800H |
8 cores, 16 threads |
16M |
3.20 GHz |
4.70 GHz |
45W |
AMD Radeon 680M 12 Core 2200MHz |
Dimension:149mm(L)x145mm(W)x40mm(H)
CPU: AMD Ryzen 9 7940HS/Ryzen 7 7840HS/Ryzen 9 6900HX/Ryzen 7 6800H
GPU: AMD Radeon 780M/680M
Ram: 2 x SO-DIMM DDR5 slots (brand Crucial, Skhynix etc)
SSD: Support 2xM.2 2280 NVME/PCIE4.0x4 (read speed 5000-7000MB/S)
HDD: Support 2.5inch 7-9mm HDD/SSD
WiFi: 802.11 AX WiFi6 with Bluethooth5.2
RJ45: 2 x 2.5G, can be configured as a host server or router
Front I/O: 2 x USB 3.2 Gen2(10Gbps), 1 x Type-C USB4.0 thunderbolt 3(40Gbps), 1 x Switch
Rear I/O: 1 x USB 3.2 Gen2(10Gbps), 3 x USB 2.0, 1 x HDMI2.1, 1 x DP1.4, 2 x 2.5G RJ45 LAN, 1 x Audio, 1 x DC-IN
OS: Windows 11 / Windows 10 etc
Power: 19V/4.74-9.47A
What's in the package
1xMini PC
1xPower supply
1xPower cable
1xSATA cable
1xVESA bracket
<p style="font-family:"Open Sans&qu
| Color | No Ram No Storage, 16GDDR5 500G PCIe4.0, 32GDDR5 500G PCIe4.0, 32G DDR5 1TB PCIe4.0, 32G DDR5 2TB PCIe4.0, 64G DDR5 1TB PCIe4.0, 64G DDR5 2TB PCIe4.0, 64G DDR5 4TB PCIe4.0 |
|---|---|
| Bundle | Ryzen 9 7940HS WiFi6, Ryzen 7 7840HS WiFi6, Ryzen 9 6900HX WiFi6, Ryzen 7 6800H WiFi6 |
| Plugs Type | us, AU, UK, EU |
| Ships From | China |
